1.ZL720 VERTICAL BAG FORMING FILLING SEALING MACHINE FOR ICE CUBE
| Model | ZL720 |
| Bags size | width :300-535mm Length:650mm |
| Capacity | Max 50bags/min |
| Reel inner dia | 75mm |
2. ZL15-S DOUBLE BUCKET WEIGHING MACHINE
Introduction:
Mainly used in agricultural products, food, chemical industry such as corn seeds, granular fertilizer and other liquidity better materials, to complete the automatic measurement, automatic filling and so on.
Features:
- Double -stand-alone weighing system, the use of cylinder self-discharge and linear vibration feeding combination of feeding, weighing accuracy.
- High-resolution single-point cantilevered sensor, high sensitivity, weighing more stable.
- Chinese touch screen interface, parameter settings at a glance, the operation more humane. Can set a variety of different product parameters, to achieve the choice of different products and measurement values.
- Humane folder bag device, safe and convenient operation, the use of toggle switch or foot switch control, can be achieved with other packaging equipment linkage work.
Technical Parameters:
Measurement range: 5kg-20kg
Measurement speed: 10-15times / min
Measurement accuracy: ± 5-8‰
Power: 220V 50HZ 0.5KW
Working pressure: 0.5 ~ 0.8MPa
Dimensions: 760X860X3144
Weighing bucket volume: 50L
Silo volume: 280L
Device Configuration
Sensor: Ningbo Ke force
Cylinder: AIR TAC
Solenoid valve: AIR TAC
Plastic bearings: Igus
Other terms :
Delivery: 45 days after receiving the buyer advance
Packing: Machine will be packed in wooden case.
Installation/ Training: The installation can be provided by the IAPACK company. It must be after shipment has arrived and factory must ready equipped with all necessary requirement before booking installation with IAPACK company . Our engineers will come to the site for the complete and final installation. During the installation session, a 2-3 day training course will be provided to the customer for operation and maintenance procedure. The salary at US$100/person/day plus all local transportation, air tickets(round trip), and minimum of 3 star hotel room & board is provided. Day charges include travel days.
Validity of the offer: 30 days
