Applications
This machine is suitable packing small bag in to big bag .The machine can automatic made the bag and fill in small bag and then sealing the big bag . This machine including the bellowing units:
- Horizontal belt conveyor for primary packaging machine.
- Slope arrangement belt conveyor;
- Acceleration belt conveyor;
- Counting and arranging machine.
- ZL1100 bag making and packing machine;
- Take off conveyor belt
Features
1 Open close device with dry auto-lubricated wads
2 Fixed bearer for vertical Seal, driven by pneumatic central cylinder
3 CLP controlled Frequency inverter, providing better velocity control for the equipment;
4 Both transverse and longitudinal seal mechanism adrived by pneumatic system
5 Frontal protection in acrylic
6 Forming tube for bales
7 better performance for leveling and vibration absortion
8 Draw down belt system;
9 Automatic unroll spool
10 Pressing or feeding conveyor
Technical Data
Bag type Pillow type bag;Gusseted bag (Option) Speed 20-50bags/min Bag Length 50 to 850mm (2.0 to 33.6in) Bag Width 80to 535mm (3.2 to 21in) Reel Film Width ≤1100mm (43.5in) Film thickness ≤1100mm (43.5in) Reel Outer Dia. 600mm (23.7in) Reel Inner Dia. 75mm (2.9in) Voltage AC220V/50Hz, 1phase or Per customer specification Compressed Air Requirement 0.6 Mpa 0.45 M3min
