Applications
Support bag width up to 350mm with 6 working postion to work with automatic taking bag, coding, opening, material filling, bag sealing and output.
Option: Nitrogen Flush, Vacuum, Spout Pouch (Conner or Center), Zip Pouch
Features
Saving pouches & less pollution the machine, no pouch or incorrect pouch opening, no fill & no seal
Graphic Interface, Well Arrange, 20 recieption, User Friendly
All strpack rotary packing machine use motor width adjust, change pouch size in a minute.
In case of door opened, machine stop to protect user
Washing down by water gun, we follow extremely water proof standard from Korea
Technical Data
- Pouch Type:Pillow Bag, 3 Side Bag, 4 Side Bag, Flat Bag
- Working Station:8Working-Station
- Filling Range:100-2000g
- Pouch Width:100-230mm
- Pouch Length:100-350mm
- Capacity:Up to 50 Bags/Min(Depends on products’ natures and filling weight)
- Dosing System:Multi-head Scale, Auger Filler, Piston Filler, Volumetric Cup
- Power Supply:Per customer specification
- Power Consumption:2KW
- Compressed Air:400 L/Min. Zip Function 580 L/Min.
- Machine Dimension:2000x1200x1400mm (78.7'x47.2'x55.1')
- Machine Weight:1200Kg
This packing line is composited by
1. Computer combination weigher
2. Material conveyor
3. Working platform
4. Vibration system
5. Exhaust or inflatable structure
6. Pressure feeding system
7. Equipment for bag feeding flatly
8. Metal detector
9. Weight sorting scales
10. Product conveyor
11. Processing tray
Attention Please
In order to offer you the exact correct Packing Lines Machine, please always give us the packing information as below
1 the materials
2 sample pouch/ bag photo
3 pouch sizes
4 packing weight
5 other specifications or requirement
FAQ
1) When can I get the price?
We usually quote within 24 hours after we get your inquiry.If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.
2) How do you make your price?
We make the price according to our comprehensive costing. And our price will lower than the trade company because we are manufacture.You will get competitive price and better quality.
3) Can you guarantee your quality?
Of course. We are the manufacture factory. More important, we put a high value on our reputation. Best quality is our principle all the time. You can be assured on our production completely.
