Applications
Loose solid material, such as puffy food, shrimp roll, peanut, popcorn, cornmeal, seed, sugar and salt etc. which shape is roll, slice and granule..
Features
- PLC controller with touch screen interface
- Servo-driven end seal jaws
- Servo-driven film transport
- Hot printer and film feeding system synchronous
- Quickly changing one-piece bag former
- Eye mark sensor for film tracking
- Stainless steel frame
Optional Device
Filling nitrogen device, gusseted device, punching jaws, chain bags device, PE fillm device,venting device.
Technical Specifications
| Model | ZVF-520 | ZVF-620 | ZVF-920 |
| Bag Size | (L)100-300mm (W)80-240mm* | (L)100-380mm* (W)100-300mm | (L) 50-380mm* (W)110-400mm |
| Bag Speed | 15- 60bags/min | 15- 60bags/min | 10-30bags/min |
| Film width | 180-500mm | 220-620mm | 340-800mm |
| Air consumption | 0.6Mps 0.36m3/min | 0.6Mps 0.4m3/min | 0.6Mps 0.7m3/min |
| Power supply | 3.0kw, 220V 50/60HZ | 4.0kw, 220V 50/60HZ | 4.5kw, 220V 50/60HZ |
| Packed Dimensions | (L)1550*(W)1160*(H)1480mm | (L)1600*(W)1260*(H)1680mm | (L)1600*(W)1500*(H)2050mm |
Linear Scale Weigher
Ideally suited for slice, roll or regular shape products: sugar, salt, seed, rice,sesame, glutamate, milk powder, coffee and seasoning powder, etc.
Principal Feature:
Adopt high precision digital load cell
Color touch screen with Multilanguage control panel
Sanitation with 304S/S construction
The parts contacted products can be easily mounted without tools
Make mix different products weighing at one discharge
Adopt no-grade vibrating feeding system to make products flowing more fluently
Program can be freely adjusted according to production condition
Can be remote-controlled and maintained through internet
With Honor Pack experience in design and manufacture, the linear weigher can be modified to suit different purpose applications.
Application:
Free Flow Powders: Detergent, Sugar, Salt, Spices, Milk powder, various sorts of powders, etc.
Granules & Seeds: Coffee beans, Rice, Sesame Seeds, Small Granules etc. Dry & Processed Foods: Snack foods, Cereal & Health Foods, Confectionary, Biscuits & Bakery, pasta, Grated Cheese, Nuts, Dried fruits, Pet Food.
Non Food: Fasteners, plumbing parts, plastic, etc.
Specification:
| Model | ZTW-2000-4H |
| Capacity | 20-2000g |
| Hopper Volume | 3000ml |
| Max. Speed | 10-50(bags/min) |
| Weighing accuracy | ±1-3g |
| Voltage | 220v/50/60Hz/5A |
| Power | 0.8KW |
| Control Panel | 20 |
| Max Mixing products | 4 |
