Description
ZL1200 Automatic bag forming filling packaging machine is special design for make the big bag from roller film and packing different product and sealing the bag .Matching with different dosing system it can use for packing rice ,bean,fertilizer ,soil earth ,sugar ,salt ,wheat flour ,milk powder and other product .
Features :
| ZL1200 vffs packaging machine |
| Machine fully controlled by Siemens PLC & Touch-Screen |
| Minute capacity can automaticly display on Touch screen |
| Film transport system and horizontal Jaw motion both drive by Panasonic |
| Safe quick change of tube and collar by just pull out the braket. |
| Optoelectronics detect film position on collar to correct film excursion |
| Electrical photo sensor inducting color code to control bag length |
| Unique Pneumatic Film-Reel locking structure to avoid film drawing deflecting |
| Independent temperature adjustment. |
| Various types of heating sealable laminated films namely PE/BOPP, CPP/BOPP, CPP/PET, PE/NYLON, aluminum foil based can be run on the machine. |
Technical parameters :
| Packaging material | PE bag or laminated film bag |
| Size of bag making | (500-650mm)x(300-520mm) |
| Measuring range | 5-20KG |
| Measurement accuracy | ±10G |
| Packaging speed | 3-8 bags/min (slight variation depending on the packaging material, bag size etc.) |
| Ambient temperature | -10°C~+45°C |
| Power | 220V 50HZ 3Kw |
| Air Consumption | 0.5~0.7MPa |
| External dimensions | 5860x2500x4140mm (L x W x H) |
| Weight | 1100kg |
FAQ
Normally we have some questions to customers,
1. What is you want to pack?
2. How many grams to pack?
3. What is volume?
4. What is voltage and Hertz in your local?
If you want to design the special packing machine, we can manufacture the packing machine as your requirements
