Applications
It’s suitable to use in packing the high accuracy and easy fragile material , such as : Potato Chips ,crispy rice , Snacks , candy , pistachio , sugar , Granular,Sugar,Salt,Bean,SeedS,Coffee,Rice..etc
Features
1.Imported PLC computer control system with human-machine interface; touch screen is simple and direct-viewing in operation;
2.precise positioning with servo film transporting system; excellent complete machine performance and nice packing;
3.minimize the loss with complete automatic warn protection function;
4.supported with metric device, the machine will automatically complete all packaging processes from measuring, feeding, filling, bag ma
5.the way of bag making: the machine can make pillow-type bag and standing bag according to customer’s requirements.
6.It could pack different kind of granule ,puffed food, rice, sugar etc.
Technical Specifications
| Type | ZVF-420 |
| Bag length | 80-300mm(L) |
| Bag width | 50-200mm(W) |
| Max width of roll film | 420mm |
| Packing speed | 5-60bags/min |
| Measuring range | 150-1200ml |
| Air consumption | 0.65mpa |
| Gas consumption | 0.3m³/min |
| Power voltage | 220V |
| Power | 2.2KW |
| Dimension | (L)1320mm×(W)950mm×(H)1360mm |
| Deadwight of machine | 540Kg |
Automatic Granule Filling Machine for Rice Nuts Sugar Salt
Model | ZTC-320 | ZTC-520 |
Speed | 30-50 drops per min (depends on product and container size) | |
Filling Range | 5 to 15ml; 2 to 20ml; 22 to 100ml; 22 to 220ml | 300ml to 1000ml |
Electrical | 220V/50HZ, 1Phase or per customized specifications | |
Power | 1kw | |
Machine Weight | 100kg | 120kg |
