Applications
For materials requiring high accuracy of measurement or careful handling, e.g. puffed food, screw, or noodles.
Various bag types are available, e.g. pouch, stand-up bag, back-sealing bag, 3 or 4 sides sealing bag, linking bags,etc
Features
Computer control and English-Chinese touch screen for easy operation without stopping the unit.
Intelligent PID temperature controller for easy adjustment and good application to various laminated film and paper.
Packaging diversification, such as back-seal bag, side gusseted bag, linked bag, hole punched bag etc.
Full automation from bag making, measuring, filling, sealing, counting and date printing.
Multi-heads scale filling system for filling accuracy and good application to various kinds of products.
Technical Specifications
| Model | ZLY520 | ZLY720 | |
| Bag style | Quad Seal Bag, pillow and gusset bag | ||
| Bag length | Up to 340mm (13.4’’) | Up to 420mm (16.5'') | |
| Bag width | 80 to 200mm (3.1’’ to 7.9’’) | 100 to 240mm (4’’ to 9.4'') | |
| Bag Side depth | 50 to 100mm (2’’ to 3.9'') | 50 to 120mm (2’’ to 4.7'') | |
| Edge Seal width | 5 to 10mm (0.2’’ to 0.4'') | ||
| Film width | ≤540mm (21.3'') | ≤730mm (28.7'') | |
| Voltage | AC220V/50Hz, 1phase or Per customer specification | ||
| Power Consumption | 3KW | 4KW | |
| Compressed Air Requirement | 0.6 MPa, 0.36 M3／min ( 87 Psi, 12.7cfm) | ||
※Above parameters are able to be customized properly as requests.
Optional Devices:
1)Gusset Device
2)Punching devices(Euroslot/normal slot)
3)Exhaust/inflatable devices
4)PE film sealing
5)Anti-Static electricity
6)Horizontal seal cooling
7)Nitrogen Charging devices
8)Vibrating device
9)Sealing Device
10)Easy tear device
Our warm service :
1. Manules / Videos of machine installation, adjusting, setting, maintenance are available to you.
2. If any problems occured and you can not find out the solutions, Telecom or Online face to face communication are available around 24 hours.
3. Shilong engineers & technician are ready to your countries for services if you agree to pay the expenditure.
4. The machine will have one year warranty. During the warranty year, if any of the parts are not broken because of misoperation, we guarantee to replace free of charge. The warranty will start counting after the machine is sent out and we received the B/L.
5. Shilong has an independent team for after-sale service. If any emergency please call the saleman or our after-sale's manager.
