Main Features
1) International famous brand of electric components such for PLC touch screen, frequency inverters, etc..
2) Adopt human-machine operation system.
3) Automatically displaying device for trouble, speed and finished products counting.
4) Machine running without pressing if no products or incorrect position of products. And stopping automatically if incorrect position of product into carton after return or no cartons or out of leaflets continuous.
5) No products not suction leaflet, no leaflet not suction carton.
6) Automatic detection and rejection device for lacking blister goods and leaflets.
7) Protecting automatically for overloading.
8) Stable performance, operation is easy.
Specification
Air Compression | 0.5 Mpa, Rate of flaw≥0.6m³/min |
Capacity | 50-90 pcs/min (The speed depends on type of products) 25-45bags/min (For zipper bag) |
Package Accuracy | Error≤±1 |
Total Power | 1.5KW (220V/380V,3PH,50HZ) |
Demension | 3200*1350*1600 (L*W*H) |
Weight | 1200KGS |
Gas Consumption | ≥20m³/h supply by user |
Application Material | Paper box: 250-350 g/m² (up to box size) Max size: 200*80*60mm (L*W*H) Min size: 55*35*14mm (L*W*H) Instruction paper: 55-65 g/m² Max size: 240*170mm (L*W) Min size: 110*90mm (L*W) |
Quick Details
Type: Packaging Line
Condition: New
Application: Commodity, Food
Packaging Type: Cartons, Other
Packaging Material: Paper
Automatic Grade: Automatic
Driven Type: Electric
Voltage: 220V/380V
Power: 1.5KW
Dimension(L*W*H): 3200*1350*1600mm(L*W*H)
Weight: 1200KGS
Certification: CE ISO9001
After-sales Service Provided: Engineers available to service machinery overseas
Warranty: 1 Year
