Description
ZL50F-25KG Automatic powder bag feeding packaging machine unit is specially suitable for powdery material, the packaging material is paper bag, PE bag, woven bag, the packing range is 10-25kg, the maximum speed can reach 3-8bags/min. High efficiency, advanced design suitable for various requirements.
Features
10-50kg packaging, with a capacity of 1000 bags/h(according to different bag, raw material)
- It’s suitable for paper bag, PE bag, woven bag. Paper bag & woven bag can adopts sewing sealing (DS-8C). PE bag adopts hot sealing (HS-22D).(Final decision according to customer’s requirements.)
- Empty bag putting process detected by detector’s dual-confirmation. Filling process stopping automatically when leakage appears or no bag putting on.
- Automatic bag feeder consists of horizontal 3 units, each unit can store 100 bags(PE bag), suitable for high speed production.
- Full automatic running.
- Additional middle damper in auger hopper (optional), air chute (optional), to prevent product splash, promote the dedusting result.
- Vibration gas exhaustion device for non pinhole bag is optional, to eliminate the rest air in the product.
Safety & Control Device
- Bag shortage detector—such as 2 units without bag, then indicator light & buzzer warning--it’s time to supply bags. When 3 units none bag—machine stop automatically.
- Fault: bag mouth opening detector—bag has been chucked auger head incorrectly, offload the bag, stop the dosing machine by signal. After this problem has been solved, restart the filling process.
- Stitching broken detector—when sewing machine stitching broken, indicator light on, buzzer sounds, whole machine stopped automatically.
- String shortage detector—indicator lights on while sewing string shortage. Buzzer sounds—it’s time to supply sewing string.
- Bag hot seal machine without automatic temperature controller or heating stripe broken detector.
Technical parameters
| Packaging material | prefabricated woven bag (lined with PP/PE film) |
| Size of bag making | (800-1000mm)x(450-550mm) LXW |
| Packaging speed | 3-15 bags/min (slight variation depending on the packaging material, bag size etc.) |
| Ambient temperature | -10°C~+45°C |
| Power | 380V 50HZ 3Kw |
| Air Consumption | 0.5~0.7MPa |
| External dimensions | 5860x2500x4140mm (L x W x H) |
| Weight | 1600kg |
