This machine is special design for vacuum packing granule product like rice bean yeast and so on .The machine with function of product weighing ,bag forming filling ,date coding .and bag sealing and so on .The output product is brick vacuum bag which are more popular in model market .
Automatically supplying materials →weighing →bag making →filling →reshaping →vacuuming →sealing & cutting →conveying
1- The unit of machine including: Z type elevator, ZL2000 Double bucket linear weighing machine,
ZL520 Vertical packaging machine, ZL-1000A vacuum machine, and product conveyor and so on.
2- High speed for packing six side bags or cubic bags Staley
3- great sealing status in good looking.
4- The unit of machine realizes automatic material conveyor, filling, packaging, reshaping, vacuuming, sealing cutting, product conveying, and dust collecting by using the PLC and touch screen.
Suitable for food, medicine, biology, chemical industry and so on.Such as dry powder,coffee powder, veterinary drugs, powder granular additives, sugar, glucose, monosodium glutamate, solid drinks, solid medicine, carbon powder, powder, pesticides, dyes, flavors, etc.
1) The whole machine is mainly made of stainless steel 304.
2) Hanging type hopper, easy to remove and wash without tools.
3) Servo motor control, optoelectronic switch control, packaging containers unlimited (bags, cans, bottles can be).
4) Can be equipped with feeding machine automatically control material level, more convenient to use, at the same time reduce labor costs, improve production efficiency.
|Bag type||brick Six side bag(cubic bag)|
|Bag Length||60 to 160mm|
|Bag Width||40 to 90mm|
|Reel Film Width||≤520mm (20.2in)|
|Film thickness||0.04-0.12mm (40-120mic.)|
|Reel Outer Dia.||500mm (19.5in)|
|Reel Inner Dia.||75mm (2.9in)|
|Voltage||AC380V/50-60Hz, 1phase or Per customer specification|
|Compressed Air Requirement||0.6 MPa0.36 M3min|
|Machine Size||L8800 x W3800 x H4800mm; (in): L343 x W148 x H187|
|Weighing accuracy||+-0.1%~+-0.5% dependent on products characteristics|
