ZTCK-G Automatic powder bag feeding packaging machine unit is specially suitable for powdery material, the packaging material is paper bag, PE bag, woven bag, the packing range is 10-25kg, the maximum speed can reach 3-8bags/min. High efficiency, advanced design suitable for various requirements.
ZTCK-G fully automatic 10kg-25kg Animal feeds/Rice/Pet food packaging machine
Brief introduction of equipment:
This unit has the functions of automatic bag supply, bag feeding, filling, bag delivery, sealing etc. It can work in linkage with the equipment for various kinds of powdery materials to achieve unmanned production operation of large-sized package
1 The machine is easy operated and stable because of adopting Siemens PLC and 10 inch color touch screen in control part.
2 Pneumatic part adopts Festo solenoid, oil- water separator, and cylinder.
3 Vacuum system adopts Festo solenoid, filter, and digital vacuum pressure switch.
4 The magnetic switch and photoelectrical switch are provided in every movement mechanism, which is safe and reliable.
1 Automatic picking-up bag system: Automatically pick up the prepared bag.
2 Opening bag, clamping, holding bag mechanism: Automatically open, hold and fix bag.
3 Hugging bag and conveying mechanism: Hugging bag and conveying bag.
4 Sewing bag: Automatic conveying bag and automatic sewing (sewing bag)
5 Electrical control part: Completely control the whole packaging unit.
6 Automatic weighing machine: ZTCK-G screw weighing machine
7 Conveyor: Convey material automatically
|Packaging material||prefabricated woven bag (lined with PP/PE film)|
|Size of bag making||(630-1100mm)x(350-650mm) LXW|
|Packaging speed||3-8 bags/min (slight variation depending on the packaging material, bag size etc.)|
|Power||220V 50HZ 3Kw|
|External dimensions||5860x2500x4140mm (L x W x H)|
